VOXAURA Showcase light, SC4001, Pole light, 24V, 3W, 2-pin Monochrome, Black

Colour Temperature: 3000K
Documentation
Brochure
CAD Data1
CAD Data2
Installation Manual
Product description

The SC4001 pole-mounted showcase light provides focused illumination for display cabinets, shelves and showcases. Its black aluminium construction combines an 18 mm spotlight head with a 350 mm overall height. Operating at 24 V and 3 W, it features a 25° beam, CRI 93 and dimming with compatible controls. Designed for recessed mounting and rated IP20. Available in separate 3000 K and 4000 K variants.

Supplied as one light with a 2 m connecting cable.

Specifications and selection

SKU 205.10.21.004

  • Colour System: Monochrome, 2-pin
  • Colour Temperature: 4000 K
  • Kind of Light: Pole light
  • Colour Rendering Index Ra: 93
  • Lumen Efficacy: 130 lm/W
  • Dimensions (LxWxH): 18 x 45 x 350 mm
  • Colour / Finish: black
  • Material: aluminium
  • Number of LEDs: 1
  • Input Voltage: 24 V DC
  • Wattage: 3 W
  • Beam Anngle: 25°
  • with Sensor: no
  • Energy Efficiency Class: E
  • Degree of Protection: IP20
  • Drill hole: Ø 14 mm
  • Installation: recessed mounting

SKU 205.10.21.003

  • Colour System: Monochrome, 2-pin
  • Colour Temperature: 3000 K
  • Kind of Light: Pole light
  • Colour Rendering Index Ra: 93
  • Lumen Efficacy: 130 lm/W
  • Dimensions (LxWxH): 18 x 45 x 350 mm
  • Colour / Finish: black
  • Material: aluminium
  • Number of LEDs: 1
  • Input Voltage: 24 V DC
  • Wattage: 3 W
  • Beam Anngle: 25°
  • with Sensor: no
  • Energy Efficiency Class: E
  • Degree of Protection: IP20
  • Drill hole: Ø 14 mm
  • Installation: recessed mounting

Select the matching SKU and dimensions for your installation. Contact KnoxOne if you need help confirming the configuration.

Product features
SKU
205.10.21.003
Colour System
Monochrome, 2-pin
Colour Temperature
3000 K
Kind of Light
Pole light
Colour Rendering Index Ra
93
Lumen Efficacy
130 lm/W
Dimensions (LxWxH)
18 x 45 x 350 mm
Colour / Finish
black
Material
aluminium
Number of LEDs
1
Input Voltage
24 V DC
Wattage
3 W
Beam Anngle
25°
with Sensor
no
Energy Efficiency Class
E
Degree of Protection
IP20
Drill hole
Ø 14 mm
Installation
recessed mounting
