VOXAURA SMD LED-Ribbon, LS4004, 24V, 10W/m, 8mm, 2-pin Monochrome, 128 LEDs/m, IP20, 5m
The LS4004 SMD LED ribbon provides white light for ceiling, showroom and task lighting. The ribbon is 8 mm wide and operates at 24 V DC, consuming 10 W/m. Light output is 1900–1950 lm/m, depending on the selected colour temperature. CRI 93 supports accurate colour rendering. It is dimmable with compatible controls and rated IP20. Available in separate 2700 K, 3000 K, 4000 K and 5000 K variants.
Supplied as one 5 m roll. Self-adhesive backing supports installation. A 2 m connecting cable and matching 2-pin, 8 mm straight connectors are sold separately. A compatible integrated driver or Smart-Driver system is sold separately. Size the driver for the installed ribbon length plus all other connected loads, keeping the combined wattage within its rated output.
Specifications and selection
SKU 200.10.00.020
- Colour System: Monochrome, 2-pin
- Colour Temperature: 5000 K
- Colour Rendering Index Ra: 93
- Luminous Flux: 1950 lm/m
- Lumen Efficacy: 195 lm/W
- Dimensions (LxWxH): 5000 x 8 x 1.5 mm
- Colour / Finish: white
- Material: plastic
- Strip Length: 5 m
- Strip Width: 8 mm
- Strip Height: 1.50 mm
- Number of LEDs: 128/m
- Input Voltage: 24 V DC
- Wattage: 10 W/m
- Beam Anngle: 120°
- with Sensor: no
- Energy Efficiency Class: B
- Degree of Protection: IP20
- Installation: self-adhesive
SKU 200.10.00.019
- Colour System: Monochrome, 2-pin
- Colour Temperature: 4000 K
- Colour Rendering Index Ra: 93
- Luminous Flux: 1950 lm/m
- Lumen Efficacy: 195 lm/W
- Dimensions (LxWxH): 5000 x 8 x 1.5 mm
- Colour / Finish: white
- Material: plastic
- Strip Length: 5 m
- Strip Width: 8 mm
- Strip Height: 1.50 mm
- Number of LEDs: 128/m
- Input Voltage: 24 V DC
- Wattage: 10 W/m
- Beam Anngle: 120°
- with Sensor: no
- Energy Efficiency Class: B
- Degree of Protection: IP20
- Installation: self-adhesive
SKU 200.10.00.018
- Colour System: Monochrome, 2-pin
- Colour Temperature: 3000 K
- Colour Rendering Index Ra: 93
- Luminous Flux: 1900 lm/m
- Lumen Efficacy: 190 lm/W
- Dimensions (LxWxH): 5000 x 8 x 1.5 mm
- Colour / Finish: white
- Material: plastic
- Strip Length: 5 m
- Strip Width: 8 mm
- Strip Height: 1.50 mm
- Number of LEDs: 128/m
- Input Voltage: 24 V DC
- Wattage: 10 W/m
- Beam Anngle: 120°
- with Sensor: no
- Energy Efficiency Class: B
- Degree of Protection: IP20
- Installation: self-adhesive
SKU 200.10.00.017
- Colour System: Monochrome, 2-pin
- Colour Temperature: 2700 K
- Colour Rendering Index Ra: 93
- Luminous Flux: 1900 lm/m
- Lumen Efficacy: 190 lm/W
- Dimensions (LxWxH): 5000 x 8 x 1.5 mm
- Colour / Finish: white
- Material: plastic
- Strip Length: 5 m
- Strip Width: 8 mm
- Strip Height: 1.50 mm
- Number of LEDs: 128/m
- Input Voltage: 24 V DC
- Wattage: 10 W/m
- Beam Anngle: 120°
- with Sensor: no
- Energy Efficiency Class: B
- Degree of Protection: IP20
- Installation: self-adhesive
Select the matching SKU and dimensions for your installation. Contact KnoxOne if you need help confirming the configuration.
